0.6/1kV交聯聚乙烯絕緣電力電纜 XLPE Insulated Power Cable
產品標準 standard 本產品按GB12706《額定電壓35KV銅芯、鋁芯塑料絕緣電力電纜》標準生產，同時還可根據用戶需要按國際電工委員會推薦標準IEC、英國標準、德國標準及美國標準生產。The product is manufactured according to the standard of GB12706、IEC.BS,DIN and ICEA upon request. 適用范圍 Applications 本產品適用于工頻額定電壓64/1KV及以下配電網或工業裝置中固定敷設之用。 The product is suitable for use in power distribution lines or fixed installations with rated power- frequency voltage up to and including 0.6/1Kv. 使用特性 Operating characteridtles ·工頻額定UO/U為0.6/1KV。 Rated power –frequency voltage UO/U為0.6/1KV。 電纜導體允許長期最高工作溫度為90℃。 Max.permissible continuous operating temperature of conductor:90℃. 短路時（最長持續時間不超過5s）電纜導體的最高溫度不超過250℃。 Max.short –circuit temperature of conductor shall not exceed 250℃(5s maximum duration ). 電纜敷設時環境溫度應不低于0℃。 The ambient temperature under installation should not below 0℃. 電纜彎曲半徑：不小于電纜外徑的15倍。 The bending radius should not less than 15 times of cable diameter.
電纜的型號 Type of cable
型號 Type
名稱 Designation
適用范圍 Application
YJV
銅芯交聯聚乙烯絕緣聚氯乙烯外護套電力電纜 Copper conductor ,XLPE insulated ,PVC sheathed power cable
室內、隧道、電纜溝內或直脈地下，能夠承受一定的機械外力和一定的拉力。 For laying indoor , in tunnel, cable French, well or direct in ground , able to bear external mechanical forces and certain pulling force.
YJLV
鋁芯交聯聚乙烯絕緣聚氯乙烯護套電力電纜 Aluminum conductor ,XLPE insulated ,PVC sheathed power cable
YJY
銅芯交聯聚乙烯絕緣聚乙烯外護套電力電纜 Copper conductor ,XLPE insulated ,PE sheathed power cable
YJLY
鋁芯交聯聚乙烯絕緣聚乙烯護套電力電纜 Aluminum conductor ,XLPE insulated ,PE sheathed power cable
電纜的型號
型號 Type
名稱 Designation
適用范圍 Application
YJLW02-Z
銅芯交聯聚乙烯絕緣皺紋鋁套聚氯乙烯外護套縱向阻水電力電纜 Copper conductor , XLPE insulated ,creasing-aluminum sheathed and PVC sheathed longitudinal-block-water power cable
室內、隧道、電纜溝內或直埋地下，可在潮濕環境及地下水位較高的地方使用，能夠承受一定的機械外力和一定的拉力 For laying indoors ,in tunnel, cable French, well or direct in ground , use in the damp place and in the high water table ,able to bear external mechanical forces and certain pulling force.
YJLLW02-Z
鋁芯交聯聚乙烯絕緣皺紋鋁套聚氯乙烯外護套縱向阻水電力電纜 Aluminum conductor , XLPE insulated ,creasing-aluminum sheathed and PVC sheathed longitudinal-block-water power cable
YJLW03-Z
銅芯交聯聚乙烯絕緣皺紋鋁套聚乙烯外護套縱向阻水電力電纜 Copper conductor , XLPE insulated ,creasing-aluminum sheathed and PE sheathed longitudinal-block-water power cable
